Marine Boat Accessory Ship Steel Grade 2 U3 Anchor Chain 20mm 40mm Studless Anchor Chain
Features:
* Three materials for your reference: Carbon steel, stainless steel, Galvanized steel
* Can be customized according to customer needs
* 24-hour online service
* For more details, please feel free to contact Customer Service.
1. Marine ship yacht boat light:
Navigation signal light, Incandescent light, Fluorescent light, Searchlight, Explosion-proof light, etc.
2. Marine deck:
Winch, Windlass, Capstan (AC, DC, Vertical, Horizontal, Electric, Hydraulic, etc.)
3. Marine deck mooring:
Anchor, Anchor chain.
4. Marine life-saving:
A rescue boat, Life Jacket, Buoy, etc.
5. Customized products according to customers' request.
Advantage:
We produce AM1, AM2, AM3 anchor chains, mooring chains, and other various specifications link chain from dia 6mm-130mm.
We also can provide all kinds of marine supporting products such as anchors, anchor chains, decking fittings, nd vessel machinery.
I. Packaging
1.Wooden Case; 2.Iron Frame; 3. According to customers' request;
II. Shipping
By Express/ Air/ Sea/ Train.
Q1: Why we choose you?
11 professional engineers can provide overall solution services.
13 years specializing in marine deck equipment.
18 long-term cooperation supporting factories.
24 hours a day after-sale technical support.
Q2: What kind of payments do you accept?
T/T, L/C, Western Union, D/A, D/P, MoneyGram, Paypal, etc..
Q3: How about the Delivery Time?
We could finish the production within 30 days
Q4: What's the MOQ?
MOQ is 1 set.
Contact Debbie Liu for more details!
| Weight of Anchor Chian Fittings |
Chain
Diameter
mm | Stud Link Chain kg/27.5m | Common
Link | Enlarged
Link | End
Link | Kenter
Shackle | Joining
Shackle | End
Shackle | Swivel | Swivel
Shackle
A.SW.S(a) | Swivel
Shackle
A.SW.S(b) |
| 14 | 128 | 0.26 | 0.39 | 0.32 | 0.6 | 0.67 | 1.5 | 1.05 | — | — |
| 16 | 150 | 0.35 | 0.49 | 0.57 | 0.65 | 0.95 | 1.52 | 1.34 | — | — |
| 17.5 | 197 | 0.5 | 0.66 | 0.67 | 0.88 | 1.34 | 2.05 | 1.73 | — | — |
| 19 | 236 | 0.66 | 0.85 | 1.06 | 1.13 | 1.84 | 2.41 | 2.17 | — | — |
| 20.5 | 268 | 0.8 | 1.02 | 1.06 | 1.36 | 2.2 | 3.25 | 2.2 | — | — |
| 22 | 324 | 1.04 | 1.3 | 1.58 | 1.64 | 2.66 | 3.95 | 3.5 | 17.5 | 7.6 |
| 24 | 370 | 1.3 | 1.65 | 1.84 | 2.13 | 3.4 | 5.12 | 4.53 | 17.5 | 9.9 |
| Mechanical Properties |
| Anchor Chain |
| Grade | Yield Point
(N/mm2,min) | Tensile Strength
(N/mm2,min) | Elongation
(%,min) | Reduction of Area
(N/mm2,min) | Impact Test (V-notch) |
| Test Temperature (°C) | Impact (J, min) |
| 2 | ≥295 | 490~690 | ≥22 | — | 0 | ≥40 |
| 3 | ≥410 | ≥690 | ≥17 | ≥40 | 0 | ≥60 |
| ≥50(weld) |
Product Tags:
|
|
Diameter 20mm 40mm Steel Grade 2 Studless Anchor Chain Images
|
